Screw Type | Dimension(mm.) | Mounting Plate | Installation Size(mm.) | ||||
Grey Door | Clear Door | W x H x D | D1 + D2 | Plastic | Metal | W3 | H3 |
TJ-MG-2030 | TJ-MT-2030 | 200x300x180 | 130+50 | TJ-2030P | TJ-2030 | 270 | 170 |
TJ-MG-3030 | TJ-MT-3030 | 300x300x180 | 130+50 | TJ-3030P | TJ-3030 | 270 | 270 |
TJ-MG-3040 | TJ-MT-3040 | 300x400x180 | 130+50 | TJ-3040P | TJ-3040 | 370 | 270 |
TJ-MG-3040-1 | TJ-MT-3040-1 | 300x400x210 | 160+50 | TJ-3040P | TJ-3040 | 370 | 270 |
TJ-MG-4050 | TJ-MT-4050 | 400x500x200 | 150+50 | TJ-4050P | TJ-4050 | 470 | 270 |
TJ-MG-4060 | TJ-MT-4060 | 400x600x220 | 170+50 | TJ-2030PX2 | TJ4060 | 570 | 370 |
